DOWN4SOUND | MM1604 (MINI MAXX) - BLACK GLOSS | 600W RMS MINI | 4 CHANNEL CAR AUDIO AMPLIFIER
- SKU:
- MM1604-BKG-
- MPN:
- MM1604-BKG-
Description
The DOWN4SOUND MM1604 Mini Maxx in Black Gloss is a compact 4 channel full range Class D car audio amplifier delivering 600W RMS of clean, efficient power for modern performance systems.
Designed for clean installations and performance builds, the MM1604 Mini Maxx provides strong multi channel output for mids and highs, active setups, or bridgeable configurations while maintaining electrical efficiency and low heat operation.
The Black Gloss edition delivers a sleek refined finish that complements black themed builds and premium installations where performance and presentation go hand in hand.
Black Gloss Finish
The black gloss housing is designed for clean installs and refined builds where visual detail matters.
- Black gloss exterior housing
- Clean show ready appearance
- Durable powder coated finish
Power Output
- 4 × 160W RMS at 4 ohms
- 4 × 220W RMS at 2 ohms
- 2 × 455W RMS at 4 ohms bridged
- 600W RMS rated output
Full range Class D architecture ensures high efficiency and stable performance in daily driven systems.
Precision Crossovers Fully Adjustable
- Full range frequency response 10Hz to 24.8kHz
- High pass filter 20Hz to 800Hz
- Low pass filter 50Hz to 800Hz
- Selectable x1 or x10 multiplier
- Band pass capable using onboard crossover controls
Flexible tuning allows precise control for mids, highs, and compact subwoofer integration.
Compact Mini Amplifier Size
- 9.84 inches × 4.87 inches × 2.13 inches
Designed for compact installations and multi amplifier systems where space efficiency matters.
Smart Protection Circuit
- Thermal protection
- Short circuit protection
- Voltage protection
- DC overload protection
Engineered for reliable operation in demanding daily use systems.
Technical Specifications
- Channels 4
- Amplifier class Full range Class D
- Frequency response 10Hz to 24.8kHz
- Input sensitivity 0.2V to 6V
- Signal to noise ratio greater than 98dB
- Total harmonic distortion less than 0.1 percent
- Operating voltage 9V to 15.5V
- Fuse rating 80A
Why Choose the MM1604 Mini Maxx Black Gloss
The MM1604 Mini Maxx delivers efficient 4 channel power in a compact chassis designed for clean modern installs. With flexible crossover tuning and bridgeable capability, it is built for systems that demand controlled output without taking up unnecessary space.
- 600W RMS rated performance
- Compact mini amplifier footprint
- Bridgeable channel flexibility
- Wide tuning capability
- Black gloss finish for refined builds
Add the MM1604 Mini Maxx Black Gloss to your system and get clean controlled power in a compact form factor.
Warranty Information
Warranty Information
Your new Down4Sound product is covered by 1 limited warranty if purchased from Down4Sound or an authorized Down4Sound dealer. This warranty does not cover improper installation, accidental damage, misuse, abuse, improper wiring, operation of unit outside of listed specifications, or any product that has been modified or repaired by anyone other than Down4Sound. Your warranty covers defects in materials and/or workmanship ONLY and is not an insurance policy. The warranty only covers the original owner of the amplifier.
All warranty returns must be accompanied by the original sales invoice or receipt. You must contact us to request an RMA number prior to sending any returns via the RMA request form on our website. You are responsible for the cost of shipping your product back to us for warranty examination. If your product is covered under warranty, shipping back to you will be at no charge to you – if your product is replaced/repaired outside of warranty you must pay for return shipping and repair bill prior returning of the product or if no defect is found you are required to pay for return shipping only.
At the sole discretion of Down4Sound your product will be either repaired or replaced when it is being covered under warranty. In the event of shipping damage due to improper packaging on products being returned to Down4Sound the customer is liable for the cost of all damages, necessary repairs, or replacement. Be sure to properly pack your return!
* Extended additional warranty purchased on amplifiers take in affect from the date of purchase and must also be stated on orginal sales invoice or receipt.
Refund/Return Policy: https://www.down4soundshop.com/shipping-returns/
Down4Sound - Hours of Operation
Additional Information
Category Type: |
Amplifiers |
Product Type: |
Amplifier |
Amplifier Type: |
4 Channel |
Amplifier Color: |
Black Gloss |
Product Color: |
Black Gloss |
