SUNDOWN AUDIO E12 v4 12" Subwoofer D4 | 500W RMS - 4 OHM

(8 reviews) Write a Review
E12D4 v.4
  • Sundown Audio SUNDOWN AUDIO E Series v4 E12 D4 12 500-watts-DVC-4OHM
  • Sundown Audio SUNDOWN AUDIO E12 v4 12 Subwoofer D4 or 500W RMS - 4 OHM
  • Sundown Audio SUNDOWN AUDIO E12 v4 12 Subwoofer D4 or 500W RMS - 4 OHM
  • Sundown Audio SUNDOWN AUDIO E12 v4 12 Subwoofer D4 or 500W RMS - 4 OHM
MSRP: $227.99
— You save $38.00


SUNDOWN AUDIO E v4 12" Subwoofer D4| 500W RMS DVC - 4 OHM

For those who like to go big or go home but on a budget, the Sundown Audio E v4 12" 500W RMS D4 Subwoofer is a perfect choice. With a double-stacked magnet structure and an extremely long voice coil, this subwoofer is designed for linear x-max of 14mm one-way. Additionally, the high mechanical clearances (over 2” peak-to-peak before physical coil bottom) give you plenty of room to experiment without fear of damaging your equipment. And if that wasn't enough, the E series V4 has been upgraded to a full 2.5” diameter coil (this started with the v.3), compared to the 2” coil of previous generations (v.1 and v.2). Plus, the tinsel leads have been upgraded to a new “Mini-XL” lead containing 63-strands of the conductor (a full XL is 84-strands and previous leads contained 42-strands) to help prevent potential failure due to amplifier clipping. Finally, the spider is a high-strength poly-cotton blend designed to handle the full capacity of the motor. So if you're looking for a powerful and reliable subwoofer, look no further than the Sundown Audio E v4 12" 500W RMS D4 Subwoofer. This design features a newly tooled, significantly stronger frame meant to resemble the cast frame on the SA v.2 and U series models.

SpecificationsSundown E12 v.4 D2SUNDOWN Audio E12 v.4 D4
RE (ohms) 3.80 5.80
FS (Hz) 30.325hz 30.645hz
Vas (L) 69.849 73.277
Qes 0.405 0.462
Qms 5.538 5.393
Qts 0.377 0.426
BL (NA) 15.912 17.863
Mms (Grams) 141.528 132.102
Cms (uM/N) 194.627 204.177
Sens (1w/1m) 88.7dB 88.5dB


E12 v.4
Sealed 1.0 ft^3
Ported 1.75 ft^3
Displacement 0.12 ft^3
Depth 6 1/2"
Outside Diameter 12 1/4"
Cut-Out 11 1/8"
Recommended Tuning 32hz
Recommended Port Area 28 in^2
